| Item / Type |
|
|
| Fan Out |
CMOS |
TTL |
| Supply Voltage |
50V ± 10%, 3.3V/2.8V/2.5V ± 10%, 1.8V ± 10% |
5.0V ± 10% |
| Frequency Range |
1.5 - 125 MHz |
1.5 - 125 MHz |
| Frequency Stability |
±50ppm/ -40 - +85°C, ±25ppm/ -20 - +70°C |
±50ppm/ -40 - +85°C, ±25ppm/ -20 - +70°C |
| Operating Temperature Range |
±20ppm/ -10 - +70°C or specify |
±20ppm/ -10 - +70°C or specify |
| Storage Temperature Range |
-55 - +125°C |
-55 - +125°C |
| Supply Current |
45mA Max, 30mA Max, 20mA Max |
45mA Max |
| Aging |
±3ppm/year Max. |
±3ppm/year Max. |
| Output Load |
15pF/50pF, 15pF/30pF, 15pF |
10 TTL gate |
| Voltage Vol(Max)/Voh(Min) |
0.1Vdd / 0.9Vdd |
0.4V / 2.4V |
| Symmetry |
40 - 60% Max. |
40 - 60% Max. |
| Rise(Tr Max.) / Fall(Tf Max.) Time |
10ns Max. |
10ns Max. |
| Startup Time |
10ms Max. |
10ms Max. |
| Integrated Jitter rms (12K-20M) |
10ps Max. |
10ps Max. |
