| Item / Type |
|
| Frequency Range |
1.843 - 200 MHz |
| Frequency Tolerance (25°C) |
±30ppm or specify |
| Frequency Stability Over Operating Temperature Range |
±30ppm or specify |
| Operating Temperature Range |
-20 - +70°C or specify |
| Shunt Capacitance |
7pF Max |
| Drive Level |
1 - 1000uW (50uW typical) |
| Load Capacitance |
Series, 16pF, 20pF, 30pF, 32pF or specify |
| Aging (25°C) |
±3ppm/year Max. |
| Storage Temperature Range |
-40 - +85°C |
|
